1000L Hermetically Sealed Agitation Tank

Product Specifications

Stainless Steel Agitation Tank for Controlled Material Processing

An agitation tank is more than a storage vessel. It must hold the process material while providing the appropriate mixing action for preparation, blending or batch processing.

For applications involving battery materials, chemicals and specialty liquids, buyers should consider not only tank capacity but also stainless steel grade, sealing structure, internal surface condition and agitation requirements.

SENLYON's 1000L stainless steel agitation tank is designed around these process variables rather than offering one fixed configuration for every application.

Hermetically Sealed Tank Structure

The enclosed structure helps isolate the material from the surrounding production environment during holding and mixing.

For materials where external contamination, dust or unnecessary exposure needs to be controlled, a sealed configuration provides a more suitable process environment than an open mixing vessel.

SUS304 or SUS316L Stainless Steel

The vessel can be manufactured from SUS304 or SUS316L stainless steel according to material compatibility and process requirements.

The correct grade should be selected according to the actual medium, chemical composition, operating environment and required corrosion resistance.

Smooth Internal Surface

Mirror-polished or customized internal surface treatment is available according to the required cleanliness and process conditions.

A smoother contact surface can also support cleaning and inspection between production batches.

Customized Mixing System

The agitation system can be configured according to the material and mixing objective rather than using one standard agitator for every process.

Relevant factors can include:

·Material characteristics

·Liquid viscosity

·Mixing or blending objective

·Batch volume

·Required mixing intensity

·Operating conditions

·Production process requirements

Agitator type, speed and configuration should be confirmed during the technical review before manufacturing.

1000L Agitation Tank for Battery Material Preparation

Lithium battery material production can require controlled storage, preparation and mixing before the material moves to the next production stage.

The 1000L Hermetically Sealed Agitation Tank can be configured for battery-related material preparation, batch mixing and compatible new-energy material processing applications.

Typical users include:

·Lithium battery material manufacturers

·Electrolyte and chemical material producers

·New energy material suppliers

·Battery production facilities

·Industrial pilot and scale-up production lines

For upstream battery raw material storage, SENLYON also manufactures 112L Stainless Steel Lithium Salt Drums for compatible lithium salts.

For liquid electrolyte storage and production transfer, see our 200L Stainless Steel Electrolyte Drum.

Chemical & Industrial Mixing Applications

In addition to lithium battery materials, this stainless steel mixing tank can be configured for compatible industrial processes requiring material holding and active agitation.

Typical applications include:

·Chemical liquid preparation

·Specialty fluid blending

·Industrial material mixing

·Batch formulation

·Process material preparation

·Pilot production expansion

·Intermediate material handling

Final tank material, surface treatment and agitation configuration should always be confirmed according to the actual medium and operating process.

Agitation Tank vs Storage Tank

A storage tank is mainly intended to hold or transfer material.

A stainless steel agitation tank adds an active mixing function, allowing the same vessel to support material preparation and processing.

If your process only requires high-purity storage and transfer without mixing, a stainless steel storage container may be more appropriate.

If the material needs to be blended, mixed or prepared before the next production stage, an agitation tank provides the more suitable process configuration.

SUS304 vs SUS316L Stainless Steel Agitation Tanks

SENLYON offers both SUS304 and SUS316L options.

SUS304 Stainless Steel

SUS304 provides good general corrosion resistance and mechanical durability for many compatible industrial processes.

It can be considered for applications where the process medium and operating environment do not require the higher corrosion resistance of SUS316L.

SUS316L Stainless Steel

SUS316L provides enhanced corrosion resistance and is often considered for more demanding chemical or high-purity process environments.

Material selection should not be based on industry name alone. The actual chemical composition, concentration, temperature and production conditions should be reviewed before the tank specification is finalized.

Custom Stainless Steel Agitation Tank Manufacturing

Different production processes require different vessel configurations. SENLYON provides OEM and ODM manufacturing based on customer drawings, existing equipment specifications or process requirements.

Customizable items include:

·Tank capacity

·Tank diameter and height

·SUS304 or SUS316L material

·Agitation system

·Agitator configuration

·Connection ports

·Filling and discharge openings

·Sealing structure

·Internal surface finish

·External surface treatment

·Accessories and fittings

If the standard 1000L configuration does not match your production line, our Custom Stainless Steel Container Service can review your requirements and develop a project-specific solution.

What Information Is Needed for Agitation Tank Selection?

Providing detailed process information before quotation helps determine a more suitable tank and mixing configuration.

We recommend providing:

1. Material being processed
Specify the liquid, slurry, powder-liquid mixture or other process material.

2. Required batch capacity
Confirm whether 1000L is the working requirement or whether another capacity is needed.

3. Material characteristics
Provide available information such as viscosity, density and material composition.

4. Mixing objective
Explain whether the process requires blending, suspension, dissolution, homogenization or another mixing result.

5. Stainless steel requirement
Specify SUS304, SUS316L or request a material recommendation based on your application.

6. Operating conditions
Provide relevant process temperature and other working conditions.

7. Connection requirements
Specify filling, discharge, transfer or other process interfaces.

8. Drawings or existing specifications
Existing equipment drawings, samples or dimensional requirements can help accelerate technical confirmation.

Manufacturing & Quality Control

SENLYON manufactures stainless steel industrial vessels with processes covering material preparation, fabrication, precision welding, surface treatment, equipment assembly and final inspection.

Quality control for the 1000L agitation tank can include:

·Raw material verification

·Dimensional inspection

·Welding quality inspection

·Surface finish inspection

·Assembly accuracy inspection

·Sealing performance testing

·Agitation system inspection

·Final finished-product inspection

Project-specific inspection or testing requirements should be confirmed before production.

Why Work with SENLYON?

Stainless Steel Fabrication Capability

SENLYON manufactures stainless steel drums, containers and process vessels using in-house fabrication, welding, grinding and polishing processes.

SUS304 & SUS316L Manufacturing

Different stainless steel grades can be selected according to chemical compatibility, corrosion resistance and process requirements.

OEM / ODM Engineering Support

Instead of limiting buyers to one standard tank configuration, SENLYON supports customized dimensions, structures, agitation systems, connections and surface treatments.

From Storage to Processing

Our product range covers different stages of industrial material handling—from lithium salt and electrolyte storage to large-volume material preparation and mixing.

This allows customers to source multiple stainless steel material-handling solutions from one manufacturer.

Packaging & Shipping

The 1000L stainless steel agitation tank is packaged according to equipment dimensions, surface protection requirements and transportation conditions.

Shipping solutions can include:

·Sea freight for international project delivery

·Reinforced export packaging

·Project-specific transport arrangements

·Customized protection for polished stainless steel surfaces

Packaging and shipment details are confirmed according to the final equipment configuration and destination.

FAQ

What is a stainless steel agitation tank?

A stainless steel agitation tank is a process vessel that combines material holding with active mixing. It can be used for blending, batch preparation and other industrial material processing applications.

What is this 1000L hermetically sealed agitation tank used for?

Typical applications include lithium battery material preparation, chemical processing, specialty liquid blending and industrial batch production.

Is a stainless steel agitation tank the same as a mixing tank?

The terms overlap substantially. A stainless steel mixing tank describes the process function, while an agitation tank specifically emphasizes the integrated agitator used to mix or move the material inside the vessel.

Can the tank be manufactured from SUS316L?

Yes. Both SUS304 and SUS316L stainless steel are available. The appropriate grade should be selected according to the material being processed and operating environment.

Can the agitation system be customized?

Yes. The agitation system can be configured according to material characteristics, mixing objectives and production requirements.

Can SENLYON manufacture capacities other than 1000L?

SENLYON manufactures stainless steel containers and vessels in multiple capacities and also supports customized production according to project requirements.

What information should I provide for a quotation?

Provide the material being processed, required capacity, material characteristics, mixing objective, stainless steel grade, operating conditions, required connections and drawings if available.

Is this tank suitable only for lithium battery materials?

No. The tank can also be configured for compatible chemical liquids, specialty fluids and other industrial material processing applications. The final configuration should be determined according to the specific medium and process conditions.

Request a Quote from a Stainless Steel Agitation Tank Manufacturer

If you are looking for a stainless steel agitation tank manufacturer for battery material preparation, chemical processing or industrial mixing, send SENLYON your process requirements.

For the 1000L Hermetically Sealed Agitation Tank, please provide your material characteristics, mixing objective, preferred stainless steel grade, connection requirements and drawings if available.

SENLYON can evaluate the standard 1000L configuration or develop a customized agitation tank according to your production process.
